Load to motor inertia ratio
Gain switch condition value
Gain switch time constant
Load to motor inertia ratio 2
Position loop gain change ratio
Speed loop gain change ratio
Speed integral gain change ratio
Parameters related to gain switching are described below.
(1) The tuning for GD1, PG1, VG1, VIC (PB06~PB09) is the same as manual-gain tuning mode, but
they are changeable in this gain switch operation.
(2) Gain switch option CDP (PB11)
It is to set the gain changing condition. Enable the trigger condition in the lowest digit. If users set
"1" here, they could use the CDP signal of DI for gain changing. The CDP signal could be assigned
to any DI pins by setting PD02~ PD09, PD21~PD24.
x=0:Invalid
x=1:CDP signal is ON
x=2:Position command frequency is equal to or higher than CDS (PB12) setting
x=3:Position command pulse error is equal to higher than CDS (PB12) setting
x=4:Motor speed is equal to or higher than CDS (PB12) setting
x=5:CDP signal is OFF
x=6:Position command frequency is less than CDS (PB12) setting
x=7:Position command pulse error is less than CDS (PB12) setting
x=8:Motor speed is less than parameter CDS (PB12) setting
