Shihlin electric SDE-100A2 User Manual

227
Low/medium inertia motor
Parts number: SDA-PWCNM1Δ-□M-L/H (low inertia 1KW, 1.5KW, 2KW, 3KW motors)
(medium inertia 1KW, 1.5KW)
-
□=2
SDA-PWCNM1-2M-L/H
□=5
SDA-PWCNM1-5M-L/H
□=10
SDA-PWCNM1-10M-L/H
Δ=B
□=2
SDA-PWCNM1B-2M-L/H (with brake)
□=5
SDA-PWCNM1B-5M-L/H (with brake)
□=10
SDA-PWCNM1B-10M-L /H (with brake)
Medium inertia motor
Parts number: SDA-PWCNM2Δ-□M-L/H (medium inertia 2KW, 3KW)
-
□=2
SDE-PWCNM2-2M-L/H
□=5
SDE-PWCNM2-5M-L/H
□=10
SDE-PWCNM2-10M-L/H
Δ=B
□=2
SDE-PWCNM2B-2M-L/H (with brake)
□=5
SDE-PWCNM2B-5M-L/H (with brake)
□=10
SDE-PWCNM2B-10M-L/H (with brake)
USB communication cable
Parts number: SDA-USB3M
