Shihlin electric SDE-100A2 User Manual

48
Status display
Sign
unit
Description
Analog Torque command
/limit voltage
U
V
Position/Speed: It denotes the analog voltage of torque limit.
Torque: It denotes the analog voltage of torque command.
Torque input command/limit
TC
%
Position/Speed: It denotes the rated torque limit percentage.
Torque: It denotes the torque command percentage.
Effective load ratio
J
%
The continuous and effective load torque is displayed relative
to the rated torque of 100%.
Peak load ratio
b
%
The highest value in the past 15 seconds is displayed relative
to the rated torque of 100%.
DC bus voltage
Pn
V
The P-N voltage of main circuit is displayed. “Lo-dC” is
shown if it is less than normal value.
Load to motor inertia ratio
dC
times
Load to motor inertia ratio is displayed.
Instantaneous torque
T
%
The Instantaneous torque value is displayed relative to the
rated torque of 100%.。
Regeneration load ratio
L
%
The permissible percentage of regenerated power is shown.
Pulses of Z phase
reference acknowledged
ZP
pulse
The pulses of Z phase reference acknowledged are shown.
Changing the parameter PA01, the status item of the servo drive at power on could be changed.
The item displayed in the initial status changes with the control mode as follows.
Control mode
Status display at power on
Position
Motor feedback pulses (Low 5-digit)
Position / speed
Motor feedback pulses(Low 5-digit) / Motor speed
Speed
Motor speed
Speed / (torque)
Motor speed /( Analog Torque command/limit voltage)
Torque
Analog Torque command/limit voltage
(Torque) / position
(Analog Torque command/limit voltage) / Motor feedback pulses(Low 5-digit)
