Adjust the Front Rails
Align the end of the rail with the end of the table
side at the 0 position.
Start at one end of the table and tighten the bolts
down the length of the rail. While performing this
step, check each side of the rail with a level or
straight edge to be sure that the rail is perfectly
straight.
Do not tighten the second rail at this time.
