ShopBot PRSalpha - Hardware

Section 3: Gantry Installation • May 2, 2016
© Copyright 2016 ShopBot Tools, Inc. page 3-2
Hardware
Part Name Quantity ShopBot Part Number Notes
Gantry
32” 1 002733
48” 1 002734
60” 1 002735
72” 1 002736
108” 1 002737
YZ Assembly
8” 1 002742
12” 1 003336
18” 1 003520
24” 1 003343
Push bar mounting kit 1 003532
1/4-20x5/8 8 002407
1/4” lock washer 8 000031
48” push bar kit 1 001996
Push bar 2 001898
1/4-20x5/8 8 002407
1/4” lock washer 8 000031
60” push bar kit 1 001997
Push bar 2 001919
1/4-20x5/8 8 002407
1/4” lock washer 8 000031
72” push bar kit 1 001998
Push bar 2 001920
1/4-20x5/8 8 002407
1/4” lock washer 8 000031
108” push bar kit 1
Push bar 2 002012
1/4-20x5/8 8 002407
1/4” lock washer 8 000031
Zip tie A/R 003100
Hard stops
X mechanical stop 4 000660
1/4-20x1/2 Hex Cap Screw 2 001006
1/4-20x3/8 Socket Head Set Screw 8 001288
