Section 7. Mounting X- and Y-Axis Motors
Introduction
The motors providing movement along the X-, Y-, and Z-axes use a geared pinion that engages a rack
mounted to the side rails and gantry. In this section the motors to power the X- and Y-axes will be
installed. The Z-axis motor comes preinstalled on the YZ car and will only need minor adjustment.
