Operating Instructions Chapter 13
M4000 Adv., Adv. A/P, Area
8010797/YT72/2016-02-19 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 117
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Application diagnostic output (ADO) PNP semiconductors, short-circuit protected
2
7)
Switching voltage HIGH (active) V
S
– 4.2 V 24 V V
S
Switching voltage LOW
(inactive)
High resistance
Switching current 0 mA 100 mA
Belt stop input/C1
Input voltage
26)
HIGH
(inactive
2
8)
, active
2
9)
)
11 V 24 V 30 V
Input current HIGH 6 mA 10 mA 20 mA
Input voltage
26)
LOW
(active
28)
, inactive
29)
)
–30 V 0 V 5 V
Input current LOW –2.5 mA 0 mA 0.5 mA
Operation time input 100 ms
Wavelength
M4000 Adv. A/P (sender unit)
Near infrared (NIR), invisible
30)
Alignment laser (optional)
3
1)
Laser class 2. Complies with IEC 60825E1:2007
and 21 CFR 1040.10 and 1040.11 with the
exception of the deviations as per Laser Notice
No. 50, June 24, 2007
Optical power output 1 mW
Wavelength 630 nm–680 nm (visible red light)
Weight, type-dependent See section 13.2 “Table of weights” on page 119ff.
Operating data
Connection Hirschmann plug M26× 11 + FE
Cable length
32)
50 m
Wire cross-section 0.75 mm
2
Ambient operating temperature –30 °C +55 °C
Air humidity
(non-dewing)
15% 95%
Storage temperature –30 °C +70 °C
Housing cross-section 52 mm × 55.5 mm
Vibration resistance 5 g, 10-55 Hz (EN 60068E2E6)
Shock resistance 10 g, 16 ms (EN 60068E2E27)
28)
Belt stop.
29)
C1.
30)
For the exact value see www.sick.com.
31)
Below –10 °C the availability of the alignment laser is limited.
32)
Depending on load, power supply and wire cross-section. The technical specifications must be observed.
