SICK nanoScan3

Display Device or configura‐
t
ion
Meaning
Configuration with
aut
omated restart
after a time
Protective field is clear, configured time to
restart expires.
Configuration with at
le
ast one warning field
Warning field interrupted (left column:num‐
ber of interrupted warning fields, right col‐
umn:number of warning fields in the current
monitoring case).
Display flashes
All devices and config‐
ur
ations
Error. All safety outputs in the OFF state.
Display flashes
All devices and config‐
ur
ations
Contamination warning.
►
Check the optics cover for damage.
►
Clean the optics cover.
Display flashes
All devices and config‐
ur
ations
Contamination error. All safety outputs in the
OFF state.
►
Check the optics cover for damage.
►
Clean the optics cover.
Display flashes
All devices and config‐
urations
Dazzle warning. Check whether the safety laser
scanner is being dazzled by an external light
source in the scan plane, e.g., sun, halogen
light, infrared light source. Remove or cover the
light source.
Display flashes
All devices and config‐
ur
ations
Dazzle error. The associated safety outputs are
in the OFF state. Check whether the safety
laser scanner is being dazzled by an external
light source in the scan plane, e.g., sun, hal‐
ogen light, infrared light source. Remove or
cover the light source.
Display flashes
Configuration with ref‐
er
ence contour field
Manipulation protection. The safety laser scan‐
ner does not detect any contour within the con‐
figured tolerance band of the reference con‐
tour field. All safety outputs in the OFF state.
Display flashes
All devices and config‐
ur
ations
Manipulation protection. The safety laser scan‐
ner measures no values within the distance
measurement range in an area of at least 90°.
All safety outputs in the OFF state.
