Number Function Color Meaning
3
Restart interlock/
w
arning field
Yellow Setup with reset: Flashes if the
restart interlock has been triggered.
Configuration with automated restart
after a time: Lights up while the con‐
figured time to restart expires.
Warning field: Lights up yellow if at
least one warning field is interrupted.
4
Display Red/yellow/green Information about the status of the
s
afety laser scanner
5
LA1: Link/activity Yellow/green
•
L
ights up green: Ethernet connec‐
tion established.
•
Flashes yellow: Data are being
transmitted.
6
NS: Network sta‐
t
us
Red/green
•
L
ights up green: Device con‐
nected, IP address present, and
CIP connection established
•
Flashes green: Device connected
and IP address present, no CIP
connection
•
Lights up red: Error, IP address
already assigned to another
device
•
Flashes red: Warning, connection
was interrupted or was then reset
or re-established
•
Flashes red/green: Connection
interrupted or terminated
7
MS: Module sta‐
t
us
Red/green
•
L
ights up green: Device in opera‐
tion
•
Flashes green: Device in sleep
mode or ready for operation
•
Lights up red: Serious error,
device not operational
•
Flashes red: Correctable error
(e.g. CIP connection interrupted)
•
Flashes red/green: Device self
test, device is currently being con‐
figured or configuration error
8
Button Operation of the display
The the ON state, OFF state and restart interlock/warning field LEDs are arranged in
t
hree sets on the base of the optics cover so that they are clearly visible from all
directions.
Complementary information
T
he display elements are only used for diagnostic purposes and are not safety-relevant.
The safety function of the device is not impaired even if the status indicators are
incorrectly displayed or fail.
9.4 Status indicator with the display
Overview
T
he display shows current information about the status of the safety laser scanner. The
display switches off after approx. 60s if all fields are clear and no other notification is
displayed.
