SICK nanoScan3

Attribute ID Access rule Name Data type Description
Dec Hex
4 0x04 Get Flags UINT Flag of the current error:
•
Bit 0.0: er
ror end. The error (or the pre‐
vious error) with the error code is no lon‐
ger present.
•
Bit 0.1: Consequential error. The error
was caused by a previous error. (If this
cannot be clearly identified, the value is
FALSE.)
•
Bit 0.2: Time stamps are based on
the network time. (If the time stamps
are based on device time, the value is
FALSE.)
•
Bit 0.3: time stamps are based on UTC.
(If the time stamps are based on an
operating hour counter or the time zone
cannot be clearly determined, the value
is FALSE.)
•
Bit 0.4: Time stamps are exact. The
value is TRUE when the deviation from
the time of the time server is less than
the maximum deviation configured.
•
Bits 1.0 … 1.7: source of the error. The
meaning of the individual bits can devi‐
ate depending on the project. Standard:
bit 0 = CPUA, bit 1 = CPUB etc. Several
bits can be set.
5 0x05 Get PowerOnCount UDINT Number of power-up processes until the
c
urrent error occurs
6 0x06 Get Errortype SHORT_STRING Error type (e.g. C1)
7 0x07 Get Errortext SHORT_STRING Error text as shown on the display
Services
•
G
et_Attribute_List
•
Get_Attributes_All
•
Get_Attribute_Single
13.5.3.2 Operating time object (0x401)
Object class
Attribute ID Access rule Name Data type
Dec Hex
1 0x01 Get Revision UINT
Services
•
G
et_Attribute_List
•
Get_Attributes_All
•
Get_Attribute_Single
Object instance
Attribute ID Access rule Name Data type Description
Dec Hex
1 0x01 Get Operating Time DATE_AND_TIME
(D
T)
If reference time is available: current time in
ms.
If reference time is not available: time since
device start in ms.
13 TECHNICAL DATA
138
