SICK nanoScan3

Attribute ID Access rule Name Data type Description
Dec Hex
2 0x02 Get Start Time DATE_AND_TIME
(D
T)
Date and time during device start.
If reference time is not available: 0.
3 0x03 Get PowerOnCount UDINT Number of power-up processes
4 0x04 Get Flags UINT
•
Bit 0.0: T
ime stamps are based on
the network time. (If the time stamps
are based on device time, the value is
FALSE.)
•
Bit 0.1: time stamps are based on UTC.
(If the time stamps are based on an
operating hour counter or the time zone
cannot be clearly determined, the value
is FALSE.)
•
Bit 0.2: Time stamps are exact. The
value is TRUE when the deviation from
the time of the time server is less than
the maximum deviation configured.
5 0x05 Get OperatingHours UDINT Operating hours of the device
Services
•
G
et_Attribute_List
•
Get_Attributes_All
•
Get_Attribute_Single
13.5.3.3 Config info object (0x402)
Object class
Attribute ID Access rule Name Data type
Dec Hex
1 0x01 Get Revision UINT
Services
•
G
et_Attribute_List
•
Get_Attributes_All
•
Get_Attribute_Single
Object instance
Attribute ID Access rule Name Data type Description
Dec Hex
1 0x01 Get DeviceName SHORT_STRING Device name
2 0x02 Get ApplicationName SHORT_STRING Application name
3 0x03 Get ProjectName SHORT_STRING Project name
4 0x04 Get UserName SHORT_STRING User name
5 0x05 Get ModificationTime DATE_AND_TIME
(D
T)
Time of the last change to the configuration
6 0x06 Get TransferTime DATE_AND_TIME
(DT)
Time of the last transmission of the configu‐
ration to the device
7 0x07 Get Reserved UDINT Reserved
8 0x08 Get AppChecksum UDINT Checksum (function)
9 0x09 Get OverallChecksum UDINT Checksum (function and network)
