SICK nanoScan3

Attribute ID Access rule Name Data type Description
Dec Hex
10 0x0A Get IntegrityHash STRUCT of Lower-level identification number of the
c
hecksums
MD5[0] UDINT
MD5[1] UDINT
MD5[2] UDINT
Reserved UDINT
Services
•
G
et_Attribute_List
•
Get_Attributes_All
•
Get_Attribute_Single
13.5.3.4 Device info object (0x403)
Object class
Attribute ID Access rule Name Data type
Dec Hex
1 0x01 Get Revision UINT
Services
•
G
et_Attribute_List
•
Get_Attributes_All
•
Get_Attribute_Single
Object instance
Attribute ID Access rule Name Data type Description
Dec Hex
1 0x01 Get PackageSerial‐
N
umber
UDINT Serial number (device with system plug)
2 0x02 Get PackageOrder‐
Number
SHORT_STRING Part number (device with system plug)
3 0x03 Get DeviceSerialNum‐
ber
UDINT Serial number (device without system plug)
4 0x04 Get DeviceOrderNum‐
ber
SHORT_STRING Part number (device without system plug)
5 0x05 Get SysplugSerialNum‐
ber
UDINT Serial number (system plug)
6 0x06 Get SysplugOrderNum‐
ber
SHORT_STRING Part number (system plug)
7 0x07 Get FirmwareVersion SHORT_STRING Current firmware version (CPU A)
8 0x08 Get CurrentConfigSet‐
V
ersion
SHORT_STRING Functionality of the configuration
9 0x09 Get HighestConfigSet‐
Version
SHORT_STRING Functionality of the device
10 0x0A Get Reserved USINT Reserved
13 TECHNICAL DATA
140
