6 COMMISSIONING
TRANSLATION OF THE ORIGINAL OPERATING INSTRUCTIONS| VMS6200
Subject to change without notice
6.3 Configuring the system with SOPAS
The volume measurement system is adjusted by configuring the measuring conditions on
site. This enables measurement, analysis, and output properties to be configured as
required.
The SOPAS ET configuration software (included) allows interactive configuration. You can
use the software to configure and test the properties, analysis behavior, and output
properties of the system as required.
6.3.1 Installing SOPAS ET
The SOPAS configuration software is installed on a PC, which is connected to a free port
on the Ethernet switch via an Ethernet cable.
The configuration software is available for download from the SICK home page.
Fig. 34: Establishing a connection between the configuration PC – and the VMS6200
▸
Using an Ethernet cable, connect the configuration PC to a free Ethernet port on the
Ethernet switch.
