1 ABOUT THIS DOCUMENT
TRANSLATION OF THE ORIGINAL OPERATING INSTRUCTIONS| VMS6200
Subject to change without notice
1.4 Further information
Special local conditions
The local laws, regulations, technical rules and internal company operating instructions at
the usage site must be observed.
Storage of documents
This document and other relevant technical documentation/information:
• Must be kept available for reference.
• Must be handed over to new system operators/new specialist personnel.
1.5 Other relevant technical documentation/information
• Technical system documentation
– EPLAN E258279
Technical data
Connection diagram
Terminal diagram
• Operating instructions for the following system components:
Operating instructions
Manufacturer
LMS5xx LASER MEASUREMENT SENSORS
SICK
MSC800 modular system controller SICK
WL(F)18-3 compact photoelectric sensors (optional) SICK
DFV60 (optional) SICK
1.6 Document conventions
Required tools
▸
Instructions
Result of action
Reference to another document.
All measurement units used in this document are metric.
Subject to change without notice.
NOTE! Illustrations may differ from the actual design.
