Technical specifications
8.5 Ambient conditions
SIMATIC IPC647E
148 Operating Instructions, 11/2018, A5E45589180-AA
8.5 Ambient conditions
See the note in "Applicability of technical specifications (Page 141)".
Climatic ambient conditions
Tested according to IEC 60068-2-2; IEC 60068-2-1; IEC 60068-2-14
Operation +0 °C up to +50 °C
1
Gradient: ≤ 10 K/h; no condensation
Storage/transport –20 °C up to +60 °C
Gradient: ≤ 20 K/h; no condensation
Tested according to IEC 60068-2-78; IEC 60068-2-30
Operation 5% up to 85% at 30 °C; no condensation
Gradient: ≤ 10 K/h; no condensation
Storage/transport 5% up to 95% at 25 °C to 55 °C; no condensation
Gradient: ≤ 20 K/h; no condensation
Operation 1080 up to 689 hPa,
corresponds to an altitude of –1000 m to 3000 m
Storage/transport 1080 up to 660 hPa,
Corresponds to an altitude of -1000 m to 3500 m
Mechanical ambient conditions
Tested according to IEC 60068-2-6; 10 cycles
2
10 to 58 Hz: 0.0375 mm, 58 Hz to 500 Hz: 4.9 m/s2
5 up to 8.51 Hz; amplitude 3.5 mm; 8.51 up to 500 Hz: 9.8 m/s2
Tested in accordance with IEC 60068-2-27
2
Half-sine: 50 m/s2, 30 ms, 100 shocks per axis
Half-sine; 250 m/s2; 6 ms; 1000 shocks per axis
In accordance with ISO 9001
Limits depend on the device equipment:
°C up to +35 °C without restriction. For information for extended ambient tempera-
ture for Type A drive cages see "
Drives in drive cage type A (Page 101)" and for Type B
drive cages see "Drives in drive cage type B (Page 110)".
The device must be free of any mechanical faults when HDD disk drives are installed in
the removable tray.
