A.2 Internal interfaces
SIMATIC IPC647E
Operating Instructions, 11/2018, A5E45589180-AA
165
A.2 Internal interfaces
A.2.1 Pin assignment of the internal interfaces
Interface
Position
Description
Memory
Internal
DIMM socket, 64-/ 72-bit
Bus expansion Internal Bus expansion socket, used by PCIe bus and
special signals
Power supply Internal 4-pin 12 V ATX power connector (CPU-VRM
supply)
BIOS Recovery
1
Internal Replace jumper on pins 3-4 to run BIOS Recov-
ery
Unlock ME
1
Internal
Replace jumper on pins 1-2 to change locked ME
Fan monitoring
Internal
Monitoring of power supply fan, 8-pin, pin header
SATA Internal, e.g.,
hard disk
7-pin SATA connector
Connection for PS serial ATA Internal Voltage supply for serial ATA
Connection for device fan Internal Power supply, device fan monitoring (controlled),
4-pin, pin header
Connection of SCSI activity
LED
Internal SCSI activity connector
Type JST B2B-PH-SM3-TB
Input for SCSI drive activity display
Internal USB3/USB2 interface Internal For connecting the USB cable to the front panel
of the computer
Internal USB2 interface
Internal
Connection for USB ports on slot plate
Port 80 connector
Internal
Connection for Port 80 / mode switch
COM2 Internal Connection for COM2 on slot cover (see external
interfaces)
Reset
Type JST B2B-PH-SM3-TB
Power button
Type JST B2B-PH-SM3-TB
PEG interface (PCIe x16 sock-
et)
Transfer interface between motherboard and bus
board.
PCIe + special signal interface
(PCIe x16 socket)
1
A special USB flash drive is required for this, (not included; contact your local SIEMENS
contact person).
