SIMATIC IPC647E
Operating Instructions, 11/2018, A5E45589180-AA
163
Hardware description
A
A.1 Motherboard
A.1.1 Layout of the motherboard
The motherboard consists of these main components: CPU and chipset, four slots for
memory modules, internal and external interfaces, FLASH BIOS and buffer battery
Figure A-1 ??? Preliminary image -> Remove motherboard and photograph it
①
Slots for memory modules
②
Processor
③
Slot for the bus board
④
Backup battery
Technical features of the motherboard
Technical features of the motherboard can be found under "Technical specifications of the
motherboard (Page 149)".
