Product description
1.4 External design of the device
SIMATIC IPC647E
Operating Instructions, 11/2018, A5E45589180-AA
21
Interfaces on the optional graphics card
You can find information on the optional graphics card under "Technical specifications of
graphic (Page 151)".
Further connection options for monitors to this interface:
● Hardware accessories (Page 29)
Interfaces at front of device
The interfaces at the front of device are located behind the front door.
2 × USB 3.1 Gen 1 Connectors for USB devices, backwards compatible with
1.4.5.2 Power supply connections
