C.5 Interfaces
SIMATIC IPC647E
Operating Instructions, 11/2018, A5E45589180-AA
193
C.5 Interfaces
Symbol
Meaning
Symbol
Meaning
Connection to the power supply
PS/2 mouse interface
Protective conductor terminal PS/2 keyboard-interface
Connection for functional earthing
(equipotential bonding line)
Multimedia Card Reader
DisplayPort interface Smart Card Reader
DVI port Line In
LAN interface, not approved for con-
necting WAN or telephone
Line Out
Serial port
Microphone input
USB port
Universal Audio Jack
USB 2.0 high-speed port
Headphone output
USB 3.0 super-speed port
USB 3.1 SuperSpeedPlus port
