Hardware description
A.5 System resources
SIMATIC IPC647E
182 Operating Instructions, 11/2018, A5E45589180-AA
PCI / PCIe cards and the on-board PCI / PCIe devices require PCI interrupt channels. These
interrupt channels can be shared and are plug-and-play compatible. that is, several devices
can share the same interrupt. The IRQ is assigned automatically.
A.5.4 Memory address assignments
The table describes the assignment of the memory addresses in the delivery state of the
device.
Address
Size
(bytes)
Description of the basic function
Possible alternative
function
from
to
FED1 0000
FED1 7FFF
4k
Motherboard resources
FED8 0000
FED1 8FFF
4k
Motherboard resources
FED9 0000
FED1 9FFF
5k
Motherboard resources
E000 0000
EFFF FFFF
8k
Motherboard resources
FED2 0000
FED3 FFFF
8k
Motherboard resources
FED9 0000
FED9 3FFF
2k
Motherboard resources
FED4 5000
FED8 FFFF
5k
Motherboard resources
FEE0 0000
FEEF FFFF
8k
Motherboard resources
FED0 0000
FED0 03FF
High precision event timer
D000 0000
FD69 FFFF
1k
Motherboard resources
FD60 0000
FD6C FFFF
1.7 GB
Motherboard resources
FD6F 0000
FDFF FFFF
2 GB
Motherboard resources
FE00 0000
FE01 FFFF
1 GB
Motherboard resources
FE20 0000
FE07 FFFF
3 GB
Motherboard resources
FF00 0000
FFFF FFFF
8 GB
Motherboard resources
FE01 0000
FE01 0FFF
4k
SPI flash Controller
