Expanding and assigning parameters to the device
6.2 Expansion cards
SIMATIC IPC647E
Operating Instructions, 11/2018, A5E45589180-AA
87
6.2 Expansion cards
6.2.1 Usable expansion cards
Expansion cards compliant with the following standards are supported
● PCI; Rev 2.3
Expansion cards with 3.3 V and 5 V supply voltage can be used.
● PCIe; Gen. 1, Gen. 2, Gen. 3
See also
Expansion card slots on the bus board (Page 173)
6.2.2 Removing/installing the bus frame
Requirement
● The device is open as described in the section "Open the device (Page 85)".
● Screwdriver T10
Procedure - Removal
Note
Observe the ESD guidelines
See
General safety instructions (Page 33).
