Siemens SIMATIC IPC647E User Manual

Technical specifications
8.7 Technical specifications of the motherboard
SIMATIC IPC647E
150 Operating Instructions, 11/2018, A5E45589180-AA
Power consumption per PCIe slot
with x16 expansion cards, max.
permissible
• 3.3 V / 3 A
• 12 V / 2.1 A
• 3.3 V
aux
/ 0.4 A
Power loss per slot at max. ambi-
ent air temperature 50 °C, permis-
sible
≤ 30 W
Power loss of all slots at max.
ambient air temperature 50 °C,
permissible
≤ 80 W
In total, the power must not exceed 3.3 V
aux
/ 1.2 A.
* Main memory interface 2400 MT/s
Expansion card slots
Expansion card slots Bus board variant 1: 2 x PCI with piggyback 2 x PCIe / 4-slot
• 1 x PCI slot; slot 1
• 1 x PCI slot; slot 4
• 1 x PCIe x16 (8 lanes) slot; slot 3
• 1 x PCIe x16 (8 lanes) slot; slot 2
Bus board variant 2: 2 x PCIe with piggyback 2 x PCIe / 4-slot
• 1 x PCIe x16 (8 lanes) slot; slot 2
• 1 x PCIe x16 (8 lanes) slot; slot 3
• 1 x PCIe x16 (4 lanes) slot; slot 1
• 1 x PCIe x16 (1 lanes) slot; slot 4
Bus board variant 3: Without piggyback 2 x PCIe / 2-slot
• 1 x PCIe x16 (16 lanes) slot; slot 4
• 1 x PCIe x16 (4 lanes) slot; slot 1
Expansion cards
For details, see "Expansion card slots on the bus board (Page 173)".

Siemens SIMATIC IPC647E Specifications

General

Brand	Siemens
Model	SIMATIC IPC647E
Category	Industrial PC
Language	English
