Operating the device
5.4 Operating RAID systems
SIMATIC IPC647E
Operating Instructions, 11/2018, A5E45589180-AA
65
9. Select ① from the list of drives you wish to install in your system and confirm your
selection.
– The mounted drive is provided with a check mark in the list
②.
– You will find the assignment of the drive to the installation location in the drive cage
after the drive name, see
③.
10. Select "Create Volume".
The following screen shows the details on the RAID system just set up (RAID Volume).
The onboard RAID system is set up.
11. Press the <Esc> multiple times in succession until you reach the "Main Page" of the
firmware/BIOS menu.
Note
Confirm "Exit Discarding Changes" message with "YES"
If when exiting the firmware/BIOS menu with the <Esc> button, the warning message
"Exit Discarding Changes" is displayed, confirm this message with "Yes".
The prenumbered settings are saved nonetheless and you can leave the firmware/BIOS
menu.
12. In the Main Page of the firmware/BIOS menu, select "Continue".
Your device continues the boot operation and switches on.
