5.4 Interfaces of batch control
This chapter deals with the following interfaces of batch control:
R Interfaces with the OS:
– OS data manager
– OS signaling system
R Interface with batch data preparation
Batch data
Batch
control
On-line
changes
Batch status
Plan data
Batch status
Control recipe
Data interface Communications interface
OS
O&M
OS
MESS
OS
DM
OS
SS
User:
user interface of
batch control
BATCH flexible-
Object Manager
Read, write, monitor
parameters
Operator messages
Status messages
Visualization
Parameter values
Visualize batch
Operator actions
Start
Batch data
preparation
Start
Figure 5-9 Interfaces of batch control
