B-25
Batch
flexible
, Manual
C79000-G7076-C650-02
To use the alignment features, mark
several objects as shown below. Then
click on one to select it as the primary
object. Its frame becomes turquoise.
Figure 23: Aligning Multiple Objects
By selecting a primary object, you de
fine the basic dimensions. Use the se
cond button pictured above to align all
objects with the top of the primary ob
ject. The second to last button makes
all marked objects the same height as
the primary object. Y
ou can select a
new primary object at any time. Sim
ply mark it with the mouse.
Unlimited Undo
Standard editors do not allow you to
undo your changes. However, the Re
portData-Editor is equipped with an
unlimited undo feature. All changes
(except changes in an object's descrip
tion) ar
e stor
ed, and you can undo
them at any time. Changes become
fixed when you save or close the lay
out.
ReportDesigner
