Siemens SINAMICS G120C DP

Number Name Factory setting
r2294 CO: Technology controller output signal - %
p2295 CO: Technology controller output scaling 100%
p2296[C] CI: Technology controller output scaling 2295
p2297[C] CI: Technology controller maximum limiting signal source 1084
p2298[C] CI: Technology controller minimum limiting signal source 1087
p2299[C] CI: Technology controller limitation o󹪜set 0
p2302 Technology controller output signal start value 0%
Table 8-57 Adapting the actual value of the technology controller
Number Name Factory setting
p2264[C] CI: Technology controller actual value 0
p2265 Technology controller actual value 󹪝lter time constant 0s
p2266 CO: Technology controller actual value after 󹪝lter - %
p2267 Technology controller upper limit actual value 100%
p2268 Technology controller lower limit actual value -100%
p2269 Technology controller gain actual value 100%
p2270 Technology controller actual value function 0
p2271 Technology controller actual value inversion 0
r2272 CO: Technology controller actual value scaled - %
Table 8-58 PID technology controller, 󹪝xed values (binary selection)
Number Name Factory setting
p2201[D] CO: Technology controller 󹪝xed value 1 10%
p2202[D] CO: Technology controller 󹪝xed value 2 20%
p2203[D] CO: Technology controller 󹪝xed value 3 30%
p2204[D] CO: Technology controller 󹪝xed value 4 40%
p2205[D] CO: Technology controller 󹪝xed value 5 50%
p2206[D] CO: Technology controller 󹪝xed value 6 60%
p2207[D] CO: Technology controller 󹪝xed value 7 70%
p2208[D] CO: Technology controller 󹪝xed value 8 80%
p2209[D] CO: Technology controller 󹪝xed value 9 90%
p2210[D] CO: Technology controller 󹪝xed value 10 100%
p2211[D] CO: Technology controller 󹪝xed value 11 110%
p2212[D] CO: Technology controller 󹪝xed value 12 120%
p2213[D] CO: Technology controller 󹪝xed value 13 130%
p2214[D] CO: Technology controller 󹪝xed value 14 140%
p2215[D] CO: Technology controller 󹪝xed value 15 150%
p2216[D] Technology controller 󹪝xed value selection method 1
r2224 CO: Technology controller 󹪝xed value active - %
Advanced commissioning
8.19PID technology controller
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 293
