Siemens SINAMICS G120C DP User Manual

Number Name Factory setting
r2225 CO/BO: Technology controller 󹪝xed value selection status
word
- %
r2229 Technology controller number actual -
Table 8-59 PID technology controller, 󹪝xed values (direct selection)
Number Name Factory setting
p2216[D] Technology controller 󹪝xed value selection method 1
p2220[C] BI: Technology controller 󹪝xed value selection bit 0 0
p2221[C] BI: Technology controller 󹪝xed value selection bit 1 0
p2222[C] BI: Technology controller 󹪝xed value selection bit 2 0
p2223[C] BI: Technology controller 󹪝xed value selection bit 3 0
r2224 CO: Technology controller 󹪝xed value active - %
r2225 CO/BO: Technology controller 󹪝xed value selection status
word
- %
r2229 Technology controller number actual -
Table 8-60 PID technology controller, motorized potentiometer
Number Name Factory setting
r2231 Technology controller motorized potentiometer setpoint
memory
- %
p2235[C] BI: Technology controller motorized potentiometer, setpoint,
raise
0
p2236[C] BI: Technology controller motorized potentiometer, setpoint,
lower
0
p2237[D] Technology controller motorized potentiometer maximum
value
100%
p2238[D] Technology controller motorized potentiometer minimum
value
-100%
p2240[D] Technology controller motorized potentiometer start value 0%
r2245 CO: Technology controller motorized potentiometer, setpoint
before RFG
- %
p2247[D] Technology controller motorized potentiometer ramp-up time 10s
p2248[D] Technology controller motorized potentiometer ramp-down
time
10s
r2250 CO: Technology controller motorized potentiometer, setpoint
after RFG
- %
Advanced commissioning
8.19PID technology controller
SINAMICS G120C Converters
294 Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK

Siemens SINAMICS G120C DP Specifications

General

Protection Rating	IP20
Frequency Range	0 to 650 Hz
Control Modes	V/f, sensorless vector control
Communication Interfaces	PROFIBUS DP
Ambient Temperature	-10 to +50 °C (without derating), -10 to +60 °C (with derating)
Overload Capacity	150 % rated current for 60 s, 200 % rated current for 3 s
Storage Temperature	-40 to +70 °C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Output Voltage	0 V to Supply Voltage
