SINUMERIK 840C (IA)

The configured texts are activated on Power on.

35 L

36 a 4 5 232 \ // Values for

37 ’– ’ ’Slide1’ ’Slide2’ ’PORTAL’ ’Loader’ L

38 d 1 1 0 L

39 L

Fig. 4.16

4.4.3.3 Configuration file BEDCONF in directory/Operation/DIAGNOS

If changes are made in the system menus NC service, PLC service and NC info,

line

d 2 5 51 127,0 105,0 102,0 // NC service PLC service NC info

must be replaced by

d 2 5 51 127,4 105,4 102,4 // NC service PLC service NC info

in this file.

4 MMC Area Diagnosis

4.4.3 BEDCONF configuration file
