SINUMERIK 840C (IA)

4.2.1 Selection of service data

Data range

Diagnosis

Service

display

service

Single

axes

Single

spindles

Further

axes/

spindles

Service Axes single display Axis 1 (1–8)

Following error

Absolute actual value

Absolute setpoint value

Abs. compensation val.

Speed set value (0.01%)

Part actual value

Contour deviation

Synchronous run error

Parameter block position control

Parameter block gear control

Service number

Fig. see Section

Start-Up

Service axes and spindles

4 MMC Area Diagnosis

4.2.1 Selection of service data
