D Menu tree: Spindle start-up function
1)
Start-up
fct. spindle
Speed
contr. loop
Position
contr. loop
Function
generator
Current
1)
contr. loop
Measure-
ment
Meas.
paras.
Contr.para
drive
Display File
functions
Measure-
ment
Meas.
paras.
Contr.para
drive
Display File
functions
Measure-
ment
Signal-
paras.
Contr.para
drive
File
functions
Contr.para
NC
Contr.para
NC
Meas.
paras.
Contr.para
drive
Display File
functions
Measure-
ment
9.1.2 Softkeys
This softkey enables the measurement or the DAC output. In order to start a
measurement with traversing operation, the traverse enabling commands set by
means of toggle field from the PLC/NC must be available. This operator action is
acknowledged by an appropriate message.
The measurement or the DAC output is enabled by selecting the Start softkey,
but can be disabled again with the Stop softkey. The function is aborted if the
Recall hardkey is pressed without a preceding NC start command.
This softkey aborts the measurement, DAC output or traversing operation
(function generator, QEC learning process) which is in progress.
9 Drive Servo Start-Up Application (as from SW 3)
9.1.1 Selection of/menu trees drive servo start-up application
1) as from SW 4
