07.97 6 NC Machine Data (NC MD), NC Setting Data (NC SD)
6.12.1 NC setting data (NC SD)
6.12 Setting data
6.12.1 NC setting data (NC SD)
All setting data (SD) take effect immediately (without POWER ON). If program processing is in
progress, they become active in the next block if they have been changed with G functions in
the part program.
Breakdown of NC setting data
SD No. 0 – 999: General values*
SD No. 2000 – 2999: Channel-specific values*
SD No. 3000 – 3999: Axis-specific values*
SD No. 4000 – 4999: Spindle-specific values*
SD No. 5000 – 5399: General bits
SD No. 5400 – 5599: Channel-specific bits
SD No. 5600 – 5799: Axis-specific bits
SD No. 6000 – 6999: Axis/Spindle converter
SD No. 7000 – 7007: Software cam
1)
The setting data are selected with the area switchover key and the
parameter and setting data softkeys.
_______
1) As from SW 3
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 6–217
SINUMERIK 840C (IA)
