4.1.3 Printing screen hardcopies
The screen hardcopies are stored in a compressed TIFF or PCX format to reduce
the transmission times via the RS 232 interface. The format is selected in two
Bedconf entries. The formats can be interpreted with Windows tools, such as
Word.
First entry, screen colour: //BCOLORMONO_DEF
a 15 1 CO for colour screen
or
a 15 1 MO for monochrome screen
Second entry, for output format: //BHARDCOPY_DEF
a 15 6 CO TIFF
or
a 15 6 MO PCX
With these settings you can create the following file formats:
Entry in BEDCONF
a 151 a 156
File format generated
CO PCX X.PCX, compressed, color
MO PCX X.PCX, compressed, monochrome
CO TIFF X.TIF, compressed, color
MO TIFF X.TIF, uncompressed, monochrome
Note With the entry in “a 151 CO” or “MO” the screen display is changed, to colour or
monochrome.
