MODIFY
OPTIONS
OK
09.95
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
4–49
SINUMERIK 840C (IA)
4.5 Activating options (as from SW3)
Press the DIAGNOSIS/START-UP/OPTIONS softkeys to change over to the Op-
tions basic display.
Fig. 4.21
Note A PLC cold restart is required before you can implement PLC expansions.
Note The total number of real axes limits the entry “Axis exists” in the menu NC config-
uration
This also applies to spindles, channels and mode groups.
Press the MODIFY OPTIONS softkey to select the function.
Press the INPUT key to save the option password.
If the password is not entered correctly, the message WRONG OPTION PASS-
WORD is displayed.
Press the OK softkey to acknowledge.
Pressing the OK softkey activates the option screen form.
The cursor keys are used for selecting the required option.
4 MMC Area Diagnosis
4.5 Activating options (as from SW3)
