07.97 6 NC Machine Data (NC MD), NC Setting Data (NC SD)
6.1.4 Breakdown of NC MDs/drive machine data
6.1.4 Breakdown of NC MDs/drive machine data
NC MD Description Softkey Section
0
to
999
General MD General data 6.2
1000
to
1599
Channel-specific MD Channel data 6.3
2000
to
3999
Axis-specific MD 1 Axial data 1 6.4
4000
to
4999
Spindle-specific MD Spindle data 6.5
5000
to
5199
General MD bits General bits 6.6.1
5200
to
5399
Spindle-specific MD bits Spindle bits 6.6.2
5400
to
5599
Channel-specific MD bits 1 Channel bits 1 6.6.3
5600
to
5999
Axis-specific MD bits 1 Axial bits 1 6.6.4
6000
to
6999
Leadscrew error
compensation bits
Compensations flags 6.6.5
9000
to
9299
Channel-specific MD bits 2 Channel bits 2 6.6.6
11000
to
17969
Axis-specific MD 2 Axial data 2 6.7
18000
to
18599
Axis-specific MD bits 2 Axial bits 2 6.7.1
20400
to
20449
MD for multi-channel display Channel memory 6.8
2400*
to
3944*
1)
MD for parameter set
switchover
Dyn. software limit switch
Collision monitoring
Various axial data –––
6000*
to
6200*
1)
MD for flexible memory
configuration
Memory configuration 6.10
1
to
18000
SIMODRIVE drive MDs
(SW 3 and higher)
––– –––
4000*
to
4740*
1)
Safety Integrated
(SW 5 and higher)
Safety functions
(see Functional Description,
Safety Integrated)
–––
_______
1) As from SW 4
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 6–5
