Diagnosis
Display by
priority
Display by
time
Messages
Alarms
Language/
Sprache
Password
PG function
09.95
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
4–4
SINUMERIK 840C (IA)
4.1.4 Selection of the Diagnosis area
Select the DIAGNOSIS area with this softkey in the area menu bar. The initial
display that appears shows you the alarms currently pending.
With the vertical softkey bar it is possible to switch to the display of the current
messages.
Fig. 4.2 Initial display of the diagnosis area
With these softkey functions you can sort the alarms/messages currently pending
by priority or chronologically.
Press this softkey to display the current messages
Switch back to display of the alarms
See Section “Simplified language switchover”
See Section “Password”
See Section 3, Start-up PLC
4 MMC Area Diagnosis
4.1.3 Printing screen hardcopies
