09.95
ï›™
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
4–56
SINUMERIK 840C (IA)
4.8 Functions up to SW 2
4.8.1 NC data management (up to SW 2)
As from SW 3 NC data management has been moved to
the Services area. Please refer to the Operator’s Guide for
more detailed information. The description below applies to
SW 1 and SW 2.
In the area DIAGNOSIS/NC DATA management, data for the NCK can be saved
to hard disk or loaded from the hard disk into the NCK memory. It is also possible
to edit them in the ASCII editor.
S NC machine data (TEA1)
S Cycle machine data (TEA4)
S Setting data (SEA)
S Cycle setting data (SEA4)
S R parameters (RPA)
S Zero offsets (ZOA)
S Tool offsets (TOA)
The correct sequence of operation is described in the Operator’s Guide up to
SW2
S Selecting NC data
Diagnosis
NC data
management
To obtain the basic display for NC data, press the softkeys DIAGNOSIS,
START-UP then NC DATA MANAGEMENT.
4 MMC Area Diagnosis
4.8 Functions up to SW 2
