Siemens SINUMERIK 840C Installation Instructions

04.96 12 Functional Descriptions
12.6.4 Transformation parameters
12.6.4 Transformation parameters
1st transformation, parameters 1 to 10
730 - 739
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
2nd transformation, parameters 1 to 10
740 - 749
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
3rd transformation, parameters 1 to 10
750 - 759
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
4th transformation, parameters 1 to 10
760 - 769
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
5th transformation, parameters 1 to 10
770 - 779
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
6th transformation, parameters 1 to 10
780 - 789
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
7th transformation, parameters 1 to 10
790 - 799
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
8th transformation, parameters 1 to 10
800 - 809
Default value Lower input value Upper input value Units
0 -99 999 999 99 999 999 units (IS)
Active on
Warm restart
The transformation parameters are needed for the 2D/3D coordinate transformation (and are of
no consequence for the TRANSMIT coordinate transformation up to SW 4).
From SW 5, transformation parameters are also required for Transmit (see description below).
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 12–23
SINUMERIK 840C (IA)
