SINUMERIK 840C (IA)

4.8.2 PLC data (up to SW 2)

As from SW 3 NC data management has been moved to

the Services area. Please refer to the Operator’s Guide for

more detailed information.

In the DIAGNOSIS PLC data management area you can save PCF files or PLC

machine data on the hard disk or load them from the hard disk into the NCK me-

mory. You can also edit them in the USER branch.

S PCF files (PCF)

S PLC machine data (TEA2)

Selecting PLC data

Diagnosis

PLC data

management

Press the softkeys DIAGNOSIS and PLC DATA management to obtain the basic

display for PLC data.

Operation continues as described in section: NC data management (up to SW 2).

4 MMC Area Diagnosis

4.8.2 PLC data (up to SW 2)
