Copy
Save to
disk
Load
from disk
09.95
ï›™
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
5–38
SINUMERIK 840C (IA)
Selected file can be copied.
The on-line file data are saved into the selected file. Here again the BOOT file
has a special status (see drive installation/start-up).
The lower user data area must be selected.
The selected file is loaded into the NCK. The on-line file and the BOOT file
cannot be loaded.
Note If the file functions are selected after an NCK Power On, the password has to be
entered again.
5.8.4.2 2nd level: File functions
Selection/ (Example
drive MD)
Diagnosis
Machine
data
Start-up
Drive
MD
Axis
(FDD)
Spindle
(MSD)
File
functions
Explanation Press the Diagnosis, Start-up, Machine data, Drive MD (e.g.) and File functions
softkeys to call up the 2nd level file functions display.
5 Machine Data Dialog (MDD – as from SW 3)
5.8.4 File functions (sequence of operation – as from SW 3)
