09.95



2-16

SINUMERIK 840C (IA)

2.11 Enter PLC machine data (up to SW 2 only)

START

Data area

Parameter

softkey

NC diagnostics

softkey

NC start-up

softkey

Press PLC MD

softkey

Go back with

RECALL key

General reset mode

softkey

END

Correct PLC MD

Entries cannot be made until

password has been entered

Start-up

end softkey

Enter PLC MD

2 General Reset and Standard Start-Up

2.11 Enter PLC machine data (up to SW 2 only)

1) SW 1 only
