09.95
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
4–41
SINUMERIK 840C (IA)
4.4.4.2 New 19” operator panel as from SW 4.5 (5)
6FC5 103–0ABVV–VAA1
Standard CLUT table There is a new standard POCOCLUT and NECOCLUT table for color. The values
entered then apply to the 19” operator panel with a 14” color screen and the 19”
slimline operator panel with a 9.5” color screen. The standard POMOCLUT and
NEMOCLUT are also adapted to the new 19” slimline operator panel with a 9.5”
monochrome screen.
If the old 19” monochrome slimline operator panel is used (with a red display) the
settings must still be made as described in the section, Color settings for mono-
chrome display.
For positive screen display: For negative screen display:
Color table POCOCLUT NECOCLUT
Standard setting
Color index
Color Red Green Blue Color Red Green Blue
0 black 0 0 0 black 0 0 0
1 red 1000 0 0 red 1000 0 0
2 green 0 690 0 green 0 760 0
3 blue 0 0 690 blue 0 0 1000
4 yellow 1000 1000 0 yellow 1000 1000 0
5 violet 565 188 439 violet 690 0 690
6 cyan 0 1000 1000 cyan 0 1000 1000
7 white 1000 1000 1000 white 1000 1000 1000
8 grey 439 439 439 grey 439 439 439
9 orange 815 439 0 orange 1000 439 0
10 free 690 690 690 free 0 0 0
11 free 0 0 0 free 0 0 0
12 grey 188 188 188 grey 188 188 188
13 petrol 0 565 439 petrol 0 565 439
14 free 0 0 0 free 0 0 0
15 free 0 0 0 free 0 0 0
4 MMC Area Diagnosis
4.4.5 Color mapping lists
01.99
