10 Axis and Spindle Installation 12.93
10.4.1 Drive optimization
10.4.1.3 Servo gain factor K
V
NC MD 252*
To achieve only negligible contour deviations with continuous path control, a high K
V
(servo
gain) factor (NC MD 252*) is required.
If the K
V
factor is too high, however, instability, overshoots and possibly excessive machine
loads result.
The maximum permissible K
V
factor depends on:
• the drive configuration
(rise time, acceleration and braking ability).
• the quality of the machine
The K
V
factor is defined as
K
V
=
Speed
Following error
[m/min]
[mm]
m/min
mm
is the unit of the K
V
factor according to VDI standard
If an empirical value for the K
V
factor is known for the machine, set this value and check for
overshooting or instability.
