08.96 12 Functional Descriptions
12.33.3 Current setpoint filter
12.33.3.1 Machine data
MD 1200: Number of current setpoint filters
MD 1201: Type of current setpoint filter
MD 1202: Natural frequency current setpoint filter 1
MD 1203: Damping current setpoint filter 1
MD 1204: Natural frequency current setpoint filter 2
MD 1205: Damping current setpoint filter 2
MD 1206: Natural frequency current setpoint filter 3
MD 1207: Damping current setpoint filter 3
MD 1208: Natural frequency current setpoint filter 4
MD 1209: Damping current setpoint filter 4
MD 1210: Blocking frequency current setpoint filter 1
MD 1211: Bandwidth current setpoint filter 1
MD 1212: Blocking frequency current setpoint filter 1
MD 1213: Counter bandwidth current setpint filter 2
MD 1214: Bandwidth current setpoint filter 2
MD 1215: Blocking frequency current setpoint filter 2
MD 1216: Counter bandwidth current setpint filter 3
MD 1217: Bandwidth current setpoint filter 3
MD 1218: Blocking frequency current setpoint filter 3
MD 1219: Counter bandwidth current setpint filter 4
MD 1220: Bandwidth current setpoint filter 4
MD 1221: Blocking frequency current setpoint filter 4
MD 1201: Type of current setpoint filter
0 Low-pass (see MD 1202/1203)
1 Bandstop (see MD 1210/1211/1212)
0 Low-pass (see MD 1204/1205)
1 Bandstop (see MD 1213/1214/1215)
0 Low-pass (see MD 1206/1207)
1 Bandstop (see MD 1216/1217/1218)
0 Low-pass (see MD 1208/1209)
1 Bandstop (see MD 1219/1220/1221)
1st filter
2nd filter
3rd filter
4th filter
Bit 0
Bit 1
Bit 2
Bit 3
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50
12–339
SINUMERIK 840C (IA)
