SINUMERIK 840C (IA)

5.8.4.3 3rd level: File functions

Selection (Example

drive MD axis)

Diagnosis

Machine

data

Start-up

Drive

Axis

(FDD)

File

functions

Explanation Press the Diagnosis, Start-up, Machine data, Drive MD (e.g.), Axis (FDD) and

File functions softkeys to call up the 3rd level file functions display.

Fig. 5.15

Explanation The functions of the softkeys are the same as for the first level. However, the

functions of the two softkeys Save and Load can be expanded.

5 Machine Data Dialog (MDD – as from SW 3)

5.8.4 File functions (sequence of operation – as from SW 3)
