09.95



4–9

SINUMERIK 840C (IA)

S Parameter set conversion

Selected parameter set is displayed.

S Service no.

See the Diagnostics Guide for the list of service nos.

Service values are displayed in double size, i.e. in position

control resolution unit (e.g. following error displayed 2000

with position control resolution 0.5 mm , the result is a true

following error of 1000 mm.
