12.93 12 Functional Descriptions

12.22.2 Functional description

Negative cam < positive cam

2nd

NC axis

1st NC axis

Machine

zero

positive

negative

Cam

range

negative

Cam

range

positive

Cam position

(positive cam)

Cam position

(negative cam)

Positive cam < negative cam

2nd

NC axis

1st NC axis

Machine

zero

positive

negative

Cam

range

negative

Cam

range

positive

Cam position

(negative cam)

Cam position

(positive cam)

12–235

SINUMERIK 840C (IA)
