12 Functional Descriptions 07.97

12.22.2 Functional description

ACTIVATE CAM/AXIS

ASSIGNMENT DB48 DR0.6

CAM/AXIS ASSIGNMENT ACTIVATED

= DB48 DR1.6

A -> as a function of PLC program

S -> as a function of system

Notes:

• A cam pair can be only ever be assigned to one NC axis at a time.

• Several pairs of cams can be activated for one axis.

• Cam signals are not output until the axes have been referenced.

• Cams must not be activated until axes have been referenced.

Output of cam signals

The cam signals are transferred in the IPO cycle to the axis-specific interface DB32

DW121+m, bits 8 to 15.

12–238
