Siemens SINUMERIK 840C Installation Instructions

07.97 12 Functional Descriptions
12.32.14 Example on a double-slide turning machine
Protection zone 4: Slide 2
Protection zone data VALUES
Motion axes
X coordinate: MD 38003 = X2
Y coordinate: MD 38043 = 0
Z coordinate: MD 38083 = Z2
FP1 vector
X coordinate: MD 38123 = 113
Y coordinate: MD 38163 = 0
Z coordinate: MD 38203 = 28
Dimension vector
X coordinate: MD 38243 = 329
Y coordinate: MD 38283 = 0
Z coordinate: MD 38323 = 344
Machine coordinate system
Number: MD 38403 = 2
Protection zone data BITS
Protection zone exists
SR exist.: MD 38763.0 = 1
Monitoring reference OFF
SR 1 - 8: MD 38803.0-7 = 00010000
SR 9 - 16: MD 38843.0-7 = 00000000
SR 17 - 20: MD 38883.0-7 = 00000000
SR 21 - 32: MD 38923.0-7 = 00000000
Protection zone 5: Turret of slide 2
Protection zone data VALUES
Motion axes
X coordinate: MD 38004 = X2
Y coordinate: MD 38044 = -
Z coordinate: MD 38084 = Z2
FP1 vector
X coordinate: MD 38124 = -32
Y coordinate: MD 38164 = 0
Z coordinate: MD 38204 = -332
Dimension vector
X coordinate: MD 38244 = 64
Y coordinate: MD 38284 = 0
Z coordinate: MD 38324 = 334
Machine coordinate system
Number: MD 38404 = 2
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 12–327
SINUMERIK 840C (IA)
