08.96 6 NC Machine Data (NC MD), NC Setting Data (NC SD)
6.10 MDs for flexible memory configuration
Memory for extended overstore (channel 1) (as from SW 5)
61020
Default value Lower input limit Upper input limit Units
1 0 1 approx. 50 KB
Active
Power On
Memory for extended overstore (channel 2) (as from SW 5)
61021
Default value Lower input limit Upper input limit Units
1 0 1 approx. 50 KB
Active
Power On
Memory for extended overstore (channel 3) (as from SW 5)
61022
Default value Lower input limit Upper input limit Units
0 0 1 approx. 50 KB
Active
Power On
Memory for extended overstore (channel 4) (as from SW 5)
61023
Default value Lower input limit Upper input limit Units
0 0 1 approx. 50 KB
Active
Power On
Memory for extended overstore (channel 5) (as from SW 5)
61024
Default value Lower input limit Upper input limit Units
0 0 1 approx. 50 KB
Active
Power On
Memory for extended overstore (channel 6) (as from SW 5)
61025
Default value Lower input limit Upper input limit Units
0 0 1 approx. 50 KB
Active
Power On
As from SW5, the function "Extended overstore" is enabled in the "Flexible memory
configuration" (fiel ncmemcfg.). The file can be edited via the MDD menu tree
Startup/Machine data/NC machine data/ETC/Flex.memory conf..
The function can be switched on or off in the channel-specific toggle field "Data for extended
overstore". If the function is switched on for a channel, for which no block buffers have been
defined, no memory is reserved. Switching on of the function requires a memory space of
approx. 50 KB per channel. As a default, the function is switched on for channels 1 and 2.
Axis 1 to axis 30
62000-
62029
Default value Lower input limit Upper input limit Units
0 0 700 000 1 measured value
Active
after SK
"Reconfigure
memory"
This MD is used to define axis-specifically how many measured values can be enabled for the
function "Extended measuring".
©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50 6–215
SINUMERIK 840C (IA)
