12.93 7 Drive Machine Data (SIMODRIVE Drive MD)
7.1.2 MSD MD (data description - SW 3)
Status of binary inputs
11
Default value Lower output limit Upper output limit Units
– – – Hex
Active
at once
Display machine data for the status of the binary inputs.
Value table:
Bit 0 Not assigned
Bit 1
Bit 2
Bit 3
Image terminal 663 (module-specific
pulse suppression IMPFR)
Image terminal 63 of I/RF unit
(central drive pulse suppression
REIMSP)
Sum signal pulse enable:
- Stored hardware sum signal
HWFRGOUT
- Pulse enable by PLC via 611D
control word
0: Pulse enable
1: Pulse disable
Bit 4 "Heat sink of power section XKKT too
hot" message
0: Overtemperature
1: Normal temperature
Bit 5 Image terminal 112 of I/RF unit (set-up
mode XEINR message)
0: Set-up mode
1: Normal mode
Bit 6 Image terminal 64 of I/RF unit (central
drive enable setpoint = 0)
0: Controller enable
1: Regenerative braking
Bit 7 Not assigned
Bit 8 Image terminal 5 of I/RF unit
(motor/power section temperature
prewarning X12T)
0: Normal range
1: Limit value exceeded
Bit 9-15 Not assigned
Speed for max. motor operational speed motor 1
14
Default value Lower input limit Upper input limit Units
Maximum motor
speed
Max. speed Max. speed rev/min
Active
at once
Machine data MD 14 defines the maximum operating speed of the main spindle motor. It acts
as the reference value of the speed setpoint interface.
Note:
The velocity of a main spindle is matched in NC-MD 4030 (maximum spindle speed). The
motor operating speed which corresponds to this maximum value must be entered in drive-MD
14. Allowance is made for any existing gear ratios in the relationship between NC-MD 4030
and drive-MD 14.
©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50 7–3
